Home > Products > ZL85L Wheel Excavator

One of the key advantages of the ZL85L Wheel Excavator is its quick setup and operation. Equipped with a powerful engine and hydraulic system, this excavator offers efficient digging, loading, and lifting capabilities.

Chat [email protected]

FEATURES Appliction Technical Parameters

FEATURES

1. Adopts imported hydraulic components, which work stably and have reliable quality;
2. Equipped with Yanmar engine, strong power enables the machine to operate at maximum efficiency;
3. In order to make the machine operate more smoothly, the bottom plate adopts a reinforced design, using specially designed thickened steel sections to make the structure sturdier;
4. Comfortable driving space and ergonomically designed driving system;

Appliction

Wheel excavators are mainly suitable for municipal maintenance projects, drainage pipeline laying, transportation construction and rapid repair, water conservancy construction, material excavation, moving and demolition, greening, and other aspects.

Technical Parameters

Specification	Operating weight	8200kg
Specification	Bucket capacity	0.3m³
Main dimension	Total length	6030mm
	Total Height	3005mm
	Rear end Turning Radius	1570mm
	Hood Height	2010mm
	Counter weight Ground Clearance	1090mm
	Upper structure width	2085mm
	Cab Height	2945mm
	Total Tire Width	2090mm
	Min. Ground Clearance	280mm
	Wheel Tread	2260mm
	Distance of swing center to rear wheel	1200mm
	Front Extension	855mm
	Back Extension	376mm
	The maximum reduction of the dozer blade	112mm
