| Performance | 1 | Rated load | 5000kg |
| 2 | Overall weight | 17000kg | |
| 3 | Rated bucket capacity | 3m3 | |
| 4 | Maximum tractive force | 168KN | |
| 5 | Maximum breakout force | ≥173KN | |
| 6 | Maximum grade ability | 35℃ | |
| 7 | Maximum dump height | 3300mm | |
| 8 | Maximum dump reach | 1300mm | |
| 9 | Overall dimension (L×W×H) | 8085×2963×3463mm | |
| 10 | Minimum turning radius | 6500mm | |
| Engine | 11 | Model | DHD10G0383 |
| 12 | Type | lnline water cooling dry cylinder injection | |
| 13 | No. of cylinder-bore/stroke | 6－126×130mm | |
| 14 | Rated Power | 162kw–2400r/min | |
| 15 | Maximum Torque | 860N.m | |
| 16 | Min Fuel-Consume Ratio | ≤215g/kw.h | |
| Transmission system | 17 | Torque Converter | Single-stage、two-phase、four-element (dual-turbine) |
| 18 | Gearbox Mode | Fixed axis type | |
| 19 | Gear Shift | forward and 4 reverse gears | |
| 20 | Maximum Speed | 39km/h | |
| Drive axles | 21 | Main reducing Spiral | bevel gear grade 1reduction |
| 22 | Decelerating mode | planetary reduction, grade 1 | |
| 23 | Wheel base (mm) | 3200mm | |
| 24 | Wheel tread | 2200mm | |
| 25 | Minimum ground clearance | 500mm | |
| Hydraulic system | 26 | System working pressure | 16MPa |
| 27 | Boom lifting time | 5.1s | |
| 28 | Total time | 9.3s | |
| 29 | Fuel tank capacity | 300L | |
| 30 | Function of leveling automatically | yes | |
|
Brake system |
31 | Service brake | air over hydraulic disc brake on 4 wheels |
| 32 | Parking brake | manual parking brake | |
| Tyre | 33 | Type specification | 23.5-25 |
| 34 | Front tyre pressure | 0.4Mpa | |
| 35 | Rear tyre pressure | 0.35Mpa |
