Wheel loaders are heavy equipment machines commonly used in construction, mining, and agricultural industries. These versatile machines are equipped with a large front bucket and are designed to efficiently scoop, lift, and transport various materials.

Chat [email protected]

Feature Appliction Technical Parameters

Feature

Engine: Equipped with WEICHAI brand engine, stable and reliable quality.

Axle: Stronger power, low fuel consumption.

Cab: It is designed for comfort and visibility, with ergonomic controls and an enclosed space to protect the operator from noise, dust, and other hazards.

Hinged: Three-layer articulated system with good balance, flexible steering and strong fatigue resistance.

Multi-level oil cooling radiator: each system dissipates heat independently, using large aperture mesh to increase the heat dissipation area and enhance the heat dissipation effect.

Brake: Dual brake booster pumps control the front and rear axle brakes respectively, improving brake safety.

Appliction

Loaders are commonly used in construction, mining, agriculture, and landscaping industries. They are versatile machines capable of handling a wide range of tasks, such as loading and transporting materials like soil, gravel, sand, and rocks. Loaders are also used for digging, leveling, excavating, and clearing debris on job sites. Additionally, loaders are essential for snow removal and waste management operations.

Technical Parameters

Main technical parameters	Bucket capacity	1.0m³
	Rated load	1800kg
	Machine weight	4500kg (add counter weight)
	Overall dimension	587019802830mm
	Wheel base	2320mm
	Wheel track	1570mm
	Bucket width*Bucket depth	2000*570mm
	Standard dumping height	3600mm
	Optional dumping height	3900/4600mm
	Turning radius	5000mm
Engine	Model	Huafeng 4102
	Pattern	In-line, 4 cylinder
	Rated power/speed	65kw/2400
	Weight	340kg
Transmission	Type	Hydraulic torque converter
	Pattern	Automatic
	Gear shift	Double H/L
	Axle	AWD, medium hub reduction
Working hydraulic system	Operating type	Mechanical single joystick
	Lifting time	5S
	Falling time	4S
Braking system	Service brake	Air hydraulic disc brake
Braking system	Parking brake	Hand brake
Tyre	Tyre	16/70-20
