1.2cbm Self-Loading Concrete Mixer

 Email: [email protected]
 Whatsapp: +639623342285

EN

Home > Products > 1.2cbm Self-Loading Concrete Mixer

The 1.2cbm self-loading concrete mixer is a convenient and efficient concrete mixing equipment with automatic loading capabilities, allowing for quick on-site mixing of concrete at construction sites.

Chat [email protected]

Feature Appliction Technical Parameters

Feature

1. Automatic feeding and mixing system.

2. Foton Lovol excavator anti roll cab.

3. American brand fully sealed rotary support

4. Sunny motor, reliable and stable quality

5. 290°rotating mixing tank, multi-directional discharge

Appliction

1. Small Construction Sites: Ideal for small construction projects such as residential buildings, small commercial structures, or renovation projects where space is limited.

2. Urban Construction: Suitable for urban areas with restricted access or narrow roads where traditional concrete mixers may have difficulty maneuvering.

3. Infrastructure Projects: Well-suited for infrastructure projects like road repairs, bridge construction, and utility installations that require frequent concrete mixing.

Technical Parameters

Vehicle Parameters	1	Model	1.2 m³
	2	Dimension	730018003450mm
	3	Wheelbase	2560mm
	4	Curb weight	4920kg
	5	Drive form	Torque converter
	6	Max. speed	30km/h
	7	Max. Grade ability	30°
	8	Min. turning radius	4700mm
	9	Min. ground clearance	280mm
Engine	10	Model	Yunnei 490 pressurize
Engine	11	Rated power	55kw
Gear box	12	Model	ZL-265 gear box
Gear box	13	Gear position	4 forward 4 backward
General parameters	14	Equipment model	JBC-12
Hydraulic system parameters	15	Reducer speed ratio	KY07-2-0
	16	Pump	CBFC50/32
	17	Motor	BM5-125
Water supply parameters	18	Water tank capacity	400L
Water supply parameters	19	Water supply type	Time relay
Maintenance refueling amount	20	Fuel oil tank	63L
	21	Hydraulic system total capacity	63L
	22	Engine oil	16L
Mixing and unloading	23	The double cone drum has a double spiral rod and a convex bottom
	24	Drum geometric capacity	1700L
	25	Drum rotation speed	13r/min
	26	Concrete production	1.2m³/tank
